匯流排選用表型 號 |
收縮範圍內徑(mm) | 厚度 (mm) |
L+T (mm) |
D (mm) |
標準包裝 |
||||
| 最小 | 最大 | 最小 | 最大 | 最小 | 最大 | 最小 | 最大 | ||
| BPTM (25KV 等級) | |||||||||
| BPTM- 15/6 - A/U | 15 | 6 | 1.2 | 2.0 | 12 | 18 | 6.5 | 12 | 30M |
| BPTM- 30/12 - A/U | 30 | 12 | 1.2 | 2.25 | 22 | 38 | 14 | 25 | 30M |
| BPTM- 50/20 - A/U | 50 | 20 | 1.2 | 2.5 | 36 | 65 | 22 | 43 | 30M |
| BPTM- 75/30 - A/U | 75 | 30 | 1.2 | 2.5 | 55 | 95 | 33 | 63 | 20M |
| BPTM- 100/40 - A/U | 100 | 40 | 1.2 | 2.5 | 70 | 130 | 44 | 86 | 25M |
| BPTM- 120/50 - A/U | 120 | 50 | 1.3 | 3.0 | 90 | 165 | 55 | 105 | 25M |
| BPTM- 175/70 - A/U | 175 | 70 | 1.3 | 2.9 | 125 | 235 | 80 | 150 | 15M |
| BPTM- 205/110 -A/U | 205 | 110 | 1.3 | 2.9 | 200 | 276 | 127 | 190 | 10M |
| BBIT (35KV 等級) | |||||||||
| BBIT -25 / 10 – A/U | 25 | 10 | 2.0 | 4.0 | 17 | 28 | 11 | 20 | 25M |
| BBIT -40 / 16 – A/U | 40 | 16 | 2.0 | 4.0 | 28 | 45 | 18 | 32 | 20M |
| BBIT -65/ 25 – A/U | 65 | 25 | 2.0 | 4.0 | 44 | 69 | 28 | 47 | 15M |
| BBIT -100 / 40 – A/U | 100 | 40 | 2.0 | 4.0 | 69 | 102 | 44 | 72 | 15M |
| BBIT -150 / 60 – A/U | 150 | 60 | 2.0 | 4.0 | 102 | 148 | 65 | 105 | 15M |
| BBIT -175 / 80 – A/U | 175 | 80 | 2.0 | 4.0 | 133 | 196 | 85 | 125 | 10M |
